Fusion Filament Winder

Compact design perfect for high volume four-axis production

The Fusion Filament Winder features four-axis motion ideal for winding pressure vessels and tubes for small to medium envelope part production.

Four axes of motion:

  • Mandrel rotation
  • Horizontal Carriage
  • Cross Carriage
  • Rotating Eye

Configurable:

  • One, three, or five spindle configuration
  • Configurable carriage travel length
  • Wet winding or prepreg winding
  • Adjustable tailstock

Intuitive Controls:

  • Equipped with the latest control system technology
  • Online diagnostics
  • Fiber and resin monitoring
  • Integrated resin meter mix dispense controls
Contact Us!

Specs & Details

Models

FUSION FILAMENT WINDER

Spindle Configuration: 1, 3, or 5 spindles
Maximum Diameter: 24 in (61 cm) for 1 or 3 spindles
12 in (30.5 cm) for 5 spindles
Maximum Length: 13ft (3.96 m) maximum
Spindle Maximum Weight: 500lbs
Spindle Maximum Speed: 120 rpm

Maximum Strands Per Spindle: 10, or 50 combined
Carriage Maximum Travel: 13ft 3 in (403.9cm)
Carriage Maximum Speed: 39 in/sec
Cross Carriage Maximum Travel: 12 in (30.5 cm)
Cross Carriage Maximum Speed: 15 in/sec
Rotating Eye: +/-90 degrees
Rotating Eye Maximum Speed: 60 rpm
